Structural Steel Detailing
Accurate shop drawings for primary and miscellaneous steel, from members and bracing to stairs, ladders, and embeds.
Precision steel detailing
Drawings that keep fabrication moving.
We turn structural intent into coordinated 3D models, precise shop drawings, and fabrication-ready deliverables for commercial, industrial, and infrastructure projects.
24h
Typical response time for new bid packages
0.5mm
A detailing mindset focused on fit-up accuracy
6+
Commercial, industrial, and infrastructure project types
Model status Issued for approval
Shop + field
What we do
Detailing support from first review to final fabrication.
We prepare each deliverable for the people who rely on it: engineers need coordination clarity, fabricators need dependable data, and site teams need drawings that make the next step clear.
SDS/2 3D Modeling
Coordinated SDS/2 models with clear member marks, connection geometry, clash review, and fabrication data.
Erection Drawings
Clear, field-ready plans, elevations, sections, and sequence notes that support confident installation.
Fabrication Packages
Fabrication-ready NC files, bolt lists, material takeoffs, reports, and organized submittal packages.
Why Vertex
Detail with confidence. Fabricate with clarity.
Checked drawings before every release
Coordinated connection and embed information
Sheet organization built for the shop floor
Responsive communication across time zones
Process
A straightforward workflow for complex steel packages.
01
Review
We review contract drawings, specifications, RFIs, and your shop standards before modelling begins.
02
Model
We build a coordinated model around members, connections, embeds, and real field constraints.
03
Deliver
You receive checked shop drawings, erection plans, reports, and files ready for fabrication.
Project fit
Flexible detailing support when your team needs it.
Whether you need overflow capacity or a dedicated detailing partner, Vertex keeps every package organized, traceable, and ready for review.
Commercial buildings
Industrial platforms
Pipe racks and skids
Stairs and handrails
Canopies and mezzanines
Miscellaneous steel
Start a package
Send the drawings. We’ll map the path to fabrication.
Share the drawings, scope notes, schedule, and required deliverables. We’ll review the package and respond with a clear next step.
